ECO Plus CTcP – Plate UV ink resistant with maximum productivity

Download
Download Datasheet
Positive offset plate for CTcP platesetter, designed to avoid baking processes. You can get the best resistance on UV inks, metallic inks, and substitute alcohol.

Technical characteristics

Plate type CTcP Positive-working
Size Max. GE 1350mm
Gauges 0,15/ 0,20/ 0,25/ 0,30/ 0,40 mm
Color Dark blue. High contrast after developed
Coating Diazo-resin coating
Spectral sensitivity 400 – 450 nm. Peak at 405 nm
Energy required 40 – 50 mJ/cm2
Resolution AM 1% – 99% lpi @ 200 lpi
Compatible platesetter All CTcP systems on market (Amsky; CRON; Luscher and BasysPrint)
Developer

Platea D11

  • Temperature | 23 ± 2 ºC
  • Time | 25 ± 5 seconds
  • Replanishment rate | 120 ml/m2
  • Anti-ox on | 100 ml/h
  • Anti-ox off | 100 ml/h
Replenisher

Platea RD1

  • Replanishment rate | 50 – 70 ml/m2
  • anti-ox on | 40 – 60 ml/h
  • anti-ox off | 40 – 60 ml/h
Gumming Plategum S1 | Finishing gum
GUM RTU | Ready to use processor machine gum
Baking

Plategum TERM | Baking gum
Baking conditions

  • Static oven | 180º – 220º C @ 5 min
  • On-line oven | 220º – 240º C @ 3 min
Safelight Coating properties are not affected up to 3 hours under white/day light
Shelf Life 4 months if storage conditions are respected (5º-30ºC and 30-80% rH)
Run Length Up to 200.000 Copies – UV Inks
Up to 400.000 Copies – Conventional Inks
NOTE: The results obtained may vary depending on the conditions of the press, papers, inks or if the use is outside our recommended values.
